Dynaudio Directivity Control
Dynaudio Directivity Control builds on a vertical, symmetrical drive unit array and an elaborate crossover topology which leads to a controlled sound radiation.
With two tweeters, two mid-range drivers and four woofers per loudspeaker, each drive unit complements its counterpart with regard to frequency response and phase relationship in such a way that an immensely accurate and defined sound radiation characteristic is achieved. The energy radiated to the room’s floor and ceiling is reduced by approximately 75 percent. This makes the M5P far less dependent on the room and its positioning much less critical, compared to any other studio monitors available.
Array Configuration
To implement DDC in the lower frequencies, the woofer cabinets are positioned directly above and below the midrange and high frequency driver middle section.
This has two acoustical advantages. First, it provides a more equally spread radiation of the lower frequencies into the room. Second, this four-woofer design combines the diaphragm surface of a larger conventional single-woofer design with the power, speed and control of four smaller, single-voice coil-magnet assemblies.
Crossover
To counteract any sonic resonance, a separate compartment isolates and provides the perfect mechanical and thermal environment for the carefully assembled, and close-tolerance selected, crossover components.
In addition, the compartment is passively ventilated at the back so that the crossover components always remain within a safe operating temperature range – even at continuous high volume levels and during extreme transients.
M Series
Features
State-of-the-art farfield studio monitor
Custom built studio monitor with only the best materials
Dynaudio Directivity Control to reduce reflexions from floor and ceiling
Highest-grade crossover with select components on glass fibre-reinforced PCB
Array configuration for a more controlled bass performance
- Status Zaprzestany
- Segment Pro
- Seria Seria M
- Typ Monitor średniego pola
- Wejścia analogowe Pasywny
- Dolna granica częstotliwości (Hz @85 dB +/- 3 dB) 28
- Górna granica częstotliwości (kHz @ 85dB +/- 3 dB) 25
- Konstrukcja obudowy Bass-reflex z wylotem z tyłu
- Zwrotnica 5-drożny
- Częstotliwości podziału zwrotnicy (Hz) 290,480,2200,8500 Hz
- Głośnik wysokotonowy 2x 1.1 cala Esotar2
- Głośnik średniotonowy 2x 5.5 cala MSP
Axel Boman, Studio Master
Find a dealer
Find your nearest Dynaudio dealer and pay them a visit today, or sign up for a listening session.
{name}
Ask for our Dynaudio specialist{specialistName}
{description}
- {productImages}
{category}
{product}
Products
M series
- Status:
- Segment:
- Seria:
- Typ:
- Wejścia analogowe:
- Maks. SPL (1m, para):
- Dolna granica częstotliwości (Hz @85 dB +/- 3 dB):
- Górna granica częstotliwości (kHz @ 85dB +/- 3 dB):
- Konstrukcja obudowy:
- Zwrotnica:
- Częstotliwości podziału zwrotnicy (Hz):
- Głośnik wysokotonowy:
M5P
- Zaprzestany
- Pro
- Seria M
- Monitor średniego pola
- Pasywny
- 28
- 25
- Bass-reflex z wylotem z tyłu
- 5-drożny
- 290,480,2200,8500 Hz
- 2x 1.1 cala Esotar2
M3VE
- Zaprzestany
- Pro
- Seria M
- Monitor średniego pola
- 2x Lab.gruppen PLM10000Q
- 133
- 22
- 21
- Bass reflex z przodu
- 3-drożny bi-amped
- 1.1 cala Esotar2
M3XE
- Zaprzestany
- Pro
- Seria M
- Monitor średniego pola
- 2x Lab.gruppen PLM10000Q
- 135
- 22
- 21
- Bass reflex z przodu
- 3-drożny quad-amped
- 1.1 cala Esotar2
